Qube Speed Dome Turaco-15X / 2MP / 15X Zoom / TVI/AHD/CVI/CVBS / Indoor PTZ Camera

SKU 95836
P 9,999.00
In stock
1
Product Details

More IP Premium Cams & Recorder Options, Click here

P1766.49 / Month for 6 Months. Pls call our Stores to inquire about qualified credit card.


Daytime Demo:


Features:

  • 4" Inch Speed Dome Indoor TVI/AHD/CVI/CVBS PTZ Camera
  • 1/2.8" progressive scan CMOS
  • 1920 × 1080 resolution
  • 15× optical zoom, 16× digital zoom
  • 120 dB true WDR (Wide Dynamic Range)
  • 3D intelligent positioning
  • Switchable TVI/AHD/CVI/CVBS video outputs


Specification:

Camera

  • Image Sensor: 1/2.8" Progressive Scan CMOS
  • Effective Pixels: 1920(H)x1080(V)
  • Signal System: NTSC
  • Minimum Illumination: Color: 0.005 Lux @(F1.6, AGC ON)
  • White Balance: AUTO/MANUAL/HAUTO/ATW/INDOOR/OUTDOOR
  • AGC: Auto/Manual
  • BLC: ON/OFF
  • HLC: Support
  • WDR: ≥ 120 dB
  • Anti-shake: On / Off
  • Shutter Time: NTSC: 1-1/10,000s
  • Day& Night: ICR
  • Digital Zoom: 16x
  • Privacy Masking: 8 privacy masks programmable
  • Auto Focus: Auto / Semi-automatic / Manual

Lens

  • Focal Length: 5 mm to 75 mm, 15× Optical
  • Zoom Speed: Approx. 2.4 s (optical, wide to tele)
  • Angle of View: 53.8° to 4.0° (wide-tele)
  • Minimum Working Distance: 10-1500mm (Wide-Tele)
  • Aperture Range: F 1.6 to F 3.5

Pan & Tilt

  • Pan Range: 360°endless
  • Pan Speed: Pan manual speed: 0.1° to 100°/s
  • Tilt Range: -5°-90° (Auto Flip )
  • Tilt Speed: Tilt manual speed: 0.1° to 80°/s
  • Tilt preset speed: 80°/s
  • Proportional Zoom: Rotation speed can be adjusted automatically according to zoom multiples
  • Number of Preset: 256
  • Patrol: 10 patrols, up to 32 presets per patrol
  • Pattern: 5 patterns, with the total recording time no less than 10 minutes
  • Power-off Memory: Support
  • Park Action: Preset/Patrol/Pattern/Pan Scan/Tilt Scan/Panorama Scan/Day Mode/Night Mode/None
  • PTZ Position Display: ON/OFF

Alarm

  • Alarm Input: 2
  • Alarm Output: 1

Input & Output

  • Video Output: Switchable TVI/AHD/CVI/CVBS video output, (NTSC or PAL composite, BNC)
  • UTC function: UTC protocol

General

  • RS-485 Protocols: Qube, Pelco-P, Pelco-D, self-adaptive
  • Menu Language: English
  • Power Supply: 12V DC
  • Power Consumption: Max.12 W
  • Working Temperature/Humidity: -30 °C-65°C(-22°F-149°F) 90% or less
  • Protection Level:TVS 4,000V lightning protection, surge protection and voltage transient protection
  • Dimensions: Ø 165 mm × 179.5 mm (Ø 6.5" × 7.1")
  • Weight (approx.): 2Kg (4.41Ib.)
