Qube PEWEE 393X 2MP FULL HD / 3.0~9.0MM / 3X ZOOM / POE

SKU 00387
P 11,399.00
In stock
1
Product Details

More IP Deluxe PTZ Camera Options, Click here

P2,013.82/ Month for 6 Months. Pls call our Stores to inquire about qualified credit card.




Specification

  • Model PEWEE 393X
Camera
  • Image Sensor 1/2.8” Exmor CMOS
  • Effective Pixels 1944(H) x 1092(V), 2 Megapixels
  • Scanning System Progressive
  • Electronic Shutter Speed 1/1 - 1/30,000s
  • Min. Illumination
  • Color: 0.05 lux@F1.6, B/W: 0.005 lux@F1.6
  • S/N Ratio
  • More than 50dB
Camera Features
  • Day/Night Auto(ICR) / Color / B/W
  • Backlight Compensation BLC / HLC / DWDR
  • White Balance Auto, ATW, Indoor, Outdoor, Manual
  • Gain Control Auto / Manual
  • Noise Reduction 2D / 3D
  • Privacy Masking Up to 24 areas
  • Digital Zoom 16x
Lens
  • Focal Length 3.0mm ~ 9.0mm(3x Optical zoom)
  • Max Aperture F1.6 ~ F2.7
  • Focus Control Auto / Manual
  • Angle of View H: 116.5° ~ 34.5°
  • Close Focus Distance 1000mm~1500mm
PTZ
  • Pan/Tilt Range Pan: 0° ~ 360° endless; Tilt: 0° ~ 90°, auto flip 180°
  • Manual Control Speed Pan: 0.1° ~ 240°/s; Tilt: 0.1° ~160°/s
  • Preset Speed Pan: 240°/s; Tilt: 160°/s
  • Preset 80(DH-SD), 255(Pelco-P/D)
  • PTZ Mode 5 Pattern, 8 Tour, 5 Auto Scan, Auto Pan
  • Speed Setup Human-oriented focal length/ speed adaptation
  • Power up Action Auto restore to previous PTZ and lens status after power failure
  • Idle Motion Activate Preset/Pan/Scan/Tour/Pattern if there is no command in the specified period
Video
  • Compression H.264 / MJPEG
  • Resolution 1080P(1920×1080)/720P(1280×720)/D1(704×576/704×480)/CIF(352×288/352×240)
  • Frame Rate Main Stream 1080P/D1(1 ~ 25/30fps), 720P(1~50/60fps)
  • Sub Stream D1/CIF(1 ~ 25/30fps)
  • Bit Rate H.264: 56K ~ 8192Kbps, MJPEG: 56K ~ 20480Kbps
Audio
  • Compression G.711a / G.711u (32kbps) / PCM (128kbps)
  • Interface 1/1 channel In/Out
Network
  • Ethernet RJ-45 (10/100Base-T)
  • Protocol IPv4/IPv6, HTTP, HTTPS, SSL, TCP/IP, UDP, UPnP, ICMP, IGMP, SNMP, RTSP, RTP, SMTP, NTP, DHCP, DNS, PPPOE, DDNS, FTP, IP Filter, QoS, Bonjour
  • ONVIF ONVIF Profile S
  • Max. User Access 20 users
  • Smart Phone
  • iPhone, iPad, Android, Windows Phone
Auxiliary Interface
  • Memory Slot Micro SD, Max 64GB
General
  • Power Supply DC12V, PoE(802.3af)
  • Power Consumption 10W
  • Working Environment -20ºC ~ 60ºC / Less than 90% RH
  • Ingress Protection IP66
  • Vandal Resistance IK10
  • Dimensions Φ160(mm) x 132(mm) / 6.3" x 5.2" inches
  • Weight 1.33kg
