Qube BLUEBIRD / 12MP / Motorized Lens / 50M / POE

SKU 11192
P 14,559.00
In stock
1
Product Details

More IP Deluxe Dome Camera Options, Click here

Pls call our Stores to inquire about qualified credit card.




Features:

  • 1/1.7” 12Megapixel progressive scan CMOS
  • Support H.264&MJPEG dual codec
  • Max 15fps@12Mp(4000×3000),25/30fps@4K(3840x2160)
  • DWDR,Day/Night(ICR), 3DNR, AWB, AGC, BLC
  • Multiple network monitoring: Web viewer, CMS(DSS/PSS) & DMSS
  • 4.1mm ~16.4mm motorized lens
  • Max. IR LEDs Length 50m
  • IP67, PoE


Specification

  • Model BLUEBIRD DZ

Camera

  • Image Sensor 1/1.7” 12Megapixel CMOS
  • Effective Pixels 4000(H)x3000(V)
  • Scanning System Progressive
  • Electronic Shutter Speed Auto/Manual, 1/3(4)~1/100000s
  • Min. Illumination 0.05Lux/F1.4(Color); 0Lux/F1.4(IR on)
  • S/N Ratio More than 50dB
  • Video Output 1 channel BNC(1.0Vp-p,75Ω)

Camera Features

  • Max. IR LEDs Length 50m
  • Day/Night Auto(ICR)/Color/B/W
  • Backlight Compensation BLC / HLC / DWDR
  • White Balance Auto/Sunny/Night/Outdoor/Customized
  • Gain Control Auto/Manual
  • Noise Reduction 3D
  • Privacy Masking Up to 4 areas
  • EIS Support
  • Ultra Defog Support
  • Smart focus Auto focus

Lens

  • Focal Length 4.1-16.4mm
  • Max Aperture F1.53
  • Focus Control Manual
  • Angle of View H: 106 ˚~ 32 ˚
  • Lens Type Motorized/ Auto Iris(DC)

Video

  • Compression H.264/H.264B/H.264H/ MJPEG
  • Resolution 12M(4000x3000)/8M(4096×2160)/8M(3840×2160)/1080P(1920×1080)/720P(1280×720) /D1(704×576) /CIF(352×288)

Frame Rate

  • Main Stream 12M(1~15fps)/8M(4096x2160) (1~25/30fps)
  • Sub Stream D1/CIF(1 ~ 25/30fps)
  • Third Stream 1080P/720P/D1(1 ~ 25/30fps)
  • Bit Rate H.264: 32Kbps~ 16Mbps
  • ROI Up to 4 areas

Audio

  • Compression G.711a / G.711u/AAC
  • Interface 1/1 channel In/Out

Smart Function(Optional)

  • Smart detection
  • Tripwire
  • Intrusion
  • Scene change
  • Missing/Abandoned
  • Audio detect
  • Defocus detect
  • Face detect

Network

  • Ethernet RJ-45 (10/100/1000Base-T)
  • Wi-Fi N/A
  • Protocol IPv4/IPv6, HTTP, HTTPS, SSL, TCP/IP, UDP, UPnP, ICMP, IGMP, SNMP,
  • RTSP, RTP, SMTP, NTP, DHCP, DNS, PPPOE, DDNS, FTP, IP Filter, QoS, Bonjour,802.1x
  • Compatibility ONVIF, PSIA, CGI
  • Max. User Access 20 users
  • Smart Phone iPhone, iPad, Android, Windows Phone

Auxiliary Interface

  • Memory Slot Micro SD, Max 128GB
  • RS485 N/A
  • Alarm 2/1 channel In/Out

General

  • Power Supply DC12V(AC24V optional), PoE (802.3at)
  • Power Consumption Max24W (IR on)
  • Working Environment -30°C~+60°C, Less than 95% RH
  • Ingress Protection
  • IP67
  • Vandal Resistance IK10
  • Dimensions Φ159mm×117.9mm
  • Weight 1.1Kg
