Qube ALLEN D-MPBW1328-VF 1.3MP ECO SAVVY / 30M IR LENGTH / VARIFOCAL LENS / POE

Pls call our Stores to inquire about qualified credit card.

Daytime Demo:

NIghttime Demo:

• Model D-MPBW1328-VF

• Image Sensor 1/3” 1.3Megapixel progressive scan Aptina CMOS
• Effective Pixels 1280(H) x 960(V)
• Scanning System Progressive
• Electronic Shutter Speed Auto/Manual, 1/3(4)~1/10000s
• Min. Illumination 0.01Lux/F1.4(Color); 0Lux/F1.4(IR on)
• S/N Ratio More than 50dB

• Video Output 1 port

• Max. IR LEDs Length 30m
• Day/Night Auto(ICR) / Color / B/W
• Backlight Compensation BLC / HLC / DWDR
• White Balance Auto/Manual
• Gain Control Auto/Manual
• Noise Reduction 3D
• Privacy Masking Up to 4 areas

• Focal Length 2.8mm~12mm
• Max Aperture F1.4
• Focus Control Manual
• Angle of View H: 92°~30°
• Lens Type Manual/ Auto Iris(DC)
• Mount Type Board-in Type

• Compression H.264/MJPEG
• Resolution 1.3M / 720P(1280×720)/D1(704×576/704×480)/
• CIF(352×288/352×240) /
• Frame Rate Main Stream 1.3M/720P(1 ~ 25/30fps) / 2M / 3M
• Sub Stream D1/CIF(1 ~ 25/30fps)
• Bit Rate H.264: 32K ~ 8192Kbps

• Compression G.711a/ G.711u/ PCM
• Interface 1/1 channel In/Out
• Network
• Ethernet RJ-45 (10/100Base-T)
• Wi-Fi N/A
• Protocol IPv4/IPv6, HTTP, HTTPS, SSL, TCP/IP, UDP, UPnP, ICMP, IGMP, SNMP, RTSP, RTP, SMTP, NTP, DHCP, DNS, PPPOE, DDNS, FTP, IP Filter, QoS, Bonjour, ONVIF ONVIF,PSIA,CGI
• Max. User Access 20users
• Smart Phone iPhone, iPad, Android, Windows Phone

• Memory Slot Micro SD, Max 64GB
• RS485 N/A
• Alarm 2/1 channel In/Out
• PIR Sensor Range N/A

• Power Supply DC12V(AC24V optional), PoE (802.3af)
• Power Consumption <7.5W
• Working Environment -30°C~+60°C, Less than 95% RH
• Ingress Protection IP66
• Vandal Resistance N/A
• Dimensions 10.8" × 3.7" × 3.7"
• Weight 1.25kg
