Qube 8CH-NVR DIPS (DYNAMIC IP SOLUTION) SMART 1U / 4 POE (Available at Davao Branch)

More IP Premium Recorder Options, Click here

P883.33 / Month for 6 Months. Pls call our Stores to inquire about qualified credit card.

Specification

Model 8CH-NVR DIPS

• Main Processor Dual-core embedded processor
• Operating System Embedded LINUX

Video

• IP Camera Input : 8 channel
• Two-way Talk : 1channel Input, 1channel Output, RCA

Display

• Interface : 1 HDMI,1 VGA
• Resolution : 1920×1080, 1280×1024, 1280×720, 1024×768
• Display Split : 1/4/8/9 1
• OSD : Camera title, Time, Video loss, Camera lock, Motion detection, Recording

Recording

• Compression : H.264/MJPEG
• Resolution: 5Mp(2560×1920)/3Mp(2048×1536)/1080P(1920×1080)/720P(1280×720)/D1 (704×576/704×480)
• Record Rate : 80Mbps
• Bit Rate: 48~ 8192kbps
• Record Mode : Manual, Schedule(Regular(Continuous), MD, Alarm), Stop
• Record Interval: 1~120 min (default: 60 min), Pre-record: 1~30 sec, Post-record: 10~300 sec

Video Detection & Alarm

• Trigger Events: Recording, PTZ, Tour, Alarm, Video Push, Email, FTP, Buzzer & Screen tips
• Video Detection: Motion Detection, MD Zones: 396(22×18), Video Loss & Camera Blank

Playback & Backup

• Sync Playback: 1/4/9
• Search Mode : Time/Date, Alarm, MD & Exact search (accurate to second), Smart search
• Playback Function: Play, Pause, Stop, Rewind, Fast play, Slow play, Next file, Previous file, Next camera, Previous camera, Full screen, Repeat, Shuffle, Backup selection, Digital zoom
• Backup Mode: USB Device/Internal SATA burner

Network

• Ethernet : 1 RJ-45 port (10/100Mbps)
• PoE : 4 ports (IEEE802.3at)
• Network Function : HTTP, TCP/IP, IPv4/IPv6, UPNP, RTSP, UDP, SMTP, NTP, DHCP, DNS, IP Filter, PPPOE, DDNS, FTP, Alarm Server, IP Search(Support Qube IP camera, DVR, NVS and etc.)
• Max. User Access : 128users
• Smart Phone : iPhone, iPad, Android, Windows Phone

Auxiliary Interface

• USB : 2 ports (2 Rear),USB2.0

General

• Power Supply : Single, DC48V/1.5A
• Power Consumption : NVR: 10W(without HDD)
• PoE: Max 25.5W for single port
• Working Environment: -10°C~+55°C / 10%~90RH / 86~106kpa
• Dimension: (W×D×H) Smart 1U,8"×8"×1.7"
• Weight: 0.5KG(without HDD)
