Qube 4LU 4 POE 4 Channel NVR

SKU 95977
P 4,100.00
Model
1
Save this product for later
Share this product with your friends
Qube 4LU 4 POE 4 Channel NVR
Product Details

More IP Premium Recorder Options, Click here

6 Months Installment Available. Pls call our Stores to inquire about qualified credit card.



Download Apps Here:



Features:

  • Support Ultra 265/H.265/H.264 video formats
  • 4 channel input
  • Plug & Play with 4 independent PoE network interfaces
  • Third-party IP cameras supported with ONVIF conformance: Profile S, Profile G, Profile T
  • Support 1-ch HDMI, 1-ch VGA, HDMI at up to 4K(3840x2160) resolution
  • Up to 8 Megapixels resolution recording
  • HDMI and VGA simultaneous output
  • 1 SATA HDD up to 10 TB
  • ANR technology to enhance the storage reliability when the network is disconnected



Specification:

Video/Audio Input

  • IP Video Input 4-ch
  • Two-way Audio Input 1-ch, RCA

Network

  • Incoming Bandwidth 40Mbpss
  • Outgoing Bandwidth 64Mbps
  • Remote Users 128
  • Protocols P2P, UPnP, NTP, DHCP, PPPoE

Video/Audio Output

  • HDMI/VGA Output HDMI: 4K (3840x2160) /30Hz, 1920x1080p /60Hz, 1920x1080p /50Hz, 1600x1200 /60Hz, 1280x1024 /60Hz, 1280x720 /60Hz, 1024x768 /60Hz
  • VGA: 1920x1080p /60Hz, 1920x1080p /50Hz, 1600x1200 /60Hz, 1280x1024 /60Hz, 1280x720 /60Hz, 1024x768 /60Hz
  • Recording Resolution 8MP/6MP/5MP/4MP/3MP/1080p/960p/720p/D1/2CIF/CIF
  • Audio Output 1-ch, RCA
  • Synchronous Playback 4-ch
  • Corridor Mode Screen 3/4

Decoding

  • Decoding format Ultra 265, H.265, H.264
  • Live view/Playback 8MP/6MP/5MP/4MP/3MP/1080p/960p/720p/D1/2CIF/CIF
  • Capability 1 x 4K@30, 2 x 4MP@30, 4 x 1080p@30, 8 x 720p@30, 16 x D1

Hard Disk

  • SATA 1 SATA interface
  • Capacity up to 10TB for each disk

Smart

  • VCA Detection Face detection, Intrusion detection, Cross line detection, Audio detection, Defocus detection, Scene change detection, Auto tracking
  • VCA Search Face search, Behavior search
  • Statistical Analysis People counting

External Interface

  • Network Interface 1 RJ-45 10M/100M self-adaptive Ethernet Interface
  • USB Interface Rear panel:2 x USB2.0

PoE

  • Interface 4 independent 100 Mbps PoE network interfaces
  • Max Power Max 30W for single port
  • Max 54W in total ( 13.5W for each ) Max 30W for single port
  • Supported Standard IEEE 802.3at, IEEE 802.3af

General

  • Power Supply 48V DC
  • Power Consumption: ≤ 8 W( without HDD ) 52V DC
  • Power Consumption: ≤ 8 W( without HDD )
  • Working Environment -10°C ~ + 55°C ( +14°F ~ +131°F ), Humidity ≤ 90% RH(non-condensing)
  • Dimensions(W×D×H) 42 × 205 × 205mm ( 1.7" × 8.1" × 8.1" ) 270mm×205mm × 42mm (10.6" ×8.1"× 1.7")
  • Weight ( without HDD ) 0.59kg ( 1.3 lb ) ≤ 0.68 Kg ( 1.50 lb )
