Qube 16CH HDCVR 720P / 5 in 1 / (Audio) "16-7P-CVR-X"

SKU 000080
P 7,700.00
In stock
1
Product Details

More CVR Recorder Options, Click here

P1,360.33/ Month for 6 Months. Pls call our Stores to inquire about qualified credit card.


Features:


  • 5 in 1 TVI/CVI/IP/AHD/Analog
  • Up to 16 cameras with 1080p realtime preview
  • H.264 dual-stream video compression
  • All channel 720P realtime or 1080P non-realtime recording
  • HDMI/VGA simultaneous video output
  • 16 channel synchronous realtime playback, GRID interface & smart search
  • 3D intelligent positioning with Qube PTZ dome camera
  • Support 1 SATA HDD up to 6TB, 2 USB2.0
  • Multiple network monitoring: Web viewer, CMS(DSS/Smart PSS)&Smart Phone(DMSS)

Model

16-7P-CVR
System
  • Main Processor
  • Embedded processor

Operating System

  • Embedded LINUX
Video
  • Input 16 channel, BNC
  • Standard Analog / 1080P/720P HDCVI Camera / IP 1080P/720P/D1/CIF IP Camera (3 in 1)


Audio
  • Input
  • Output
  • 1 channel, RCA
  • Two-way Talk
  • Reuse audio input/output channel 1
Display
  • Interface
  • 1 HDMI, 1 VGA
Resolution
  • 1920×1080, 1280×1024, 1280×720, 1024×768
  • Display Split
  • 1/4/8/9/16\
  • Privacy Masking
  • 4 rectangular zones (each camera)
  • OSD
  • Camera title, Time, Video loss, Camera lock, Motion detection, Recording
Recording
  • Video/Audio Compression H.264/G.711
  • Resolution: 1080P(1920×1080)/720P(1280×720)/960H(960×576/960×480)/D1/4CIF(704×576/704×480) / CIF(352×288/352×240) / QCIF(176×144/176×120)
  • Record Rate
  • Main Stream: 1080P(1~12/15fps)/720P/960H/D1/HD1/2CIF/CIF(1~25/30fps)
  • Extra Stream CIF/QCIF(1~25/30fps), D1(1~12/15fps)
  • Bit Rate 48~4096Kb/s
Record Mode
  • Manual, Schedule(Regular(Continuous), MD), Stop
  • Record Interval1~60 min (default: 60 min), Pre-record: 1~30 sec, Post-record: 10~300 sec
  • Video Detection
  • Trigger Events
  • Recording, PTZ, Tour, Video Push, Email, FTP, Spot, Snapshot, Buzzer & Screen tips
Video Detection
  • Motion Detection, MD Zones: 396(22×18), Video Loss & Camera Blank
  • Playback & Backup
  • Sync Playback 1/4/9/16
  • Search Mode
  • Time/Date, MD & Exact search (accurate to second)
Playback Functions
  • Play, Pause, Stop, Rewind, Fast play, Slow play, Next file, Previous file, Next camera, Previous camera, Full screen, Repeat, Shuffle, Backup selection, Digital zoom
Backup Mode
  • USB Device/Internal SATA burner/Network
Network
  • Ethernet RJ-45 port (10/100M)
Network Functions
  • HTTP, IPv4/IPv6, TCP/IP, UPNP, RTSP, UDP, SMTP, NTP, DHCP, DNS, PPPOE, DDNS, FTP, IP Filter, SNMP, P2P
  • Max. User Access 128 users
  • Smart Phone iPhone, iPad, Android, Windows Phone
Storage
  • Internal HDD1 SATA port, up to 6TB

Auxiliary Interface

  • USB Interface 2 ports(1 Rear), USB2.0
  • RS485 1 port, For PTZ Control

General

  • Power Supply DC12V/3A
  • Power Consumption 10W(without HDD)
  • Working Environment -10°C ~+55°C / 10%~90%RH / 86~106kpa
  • Dimension(W×D×H) Mini 1U, 325mm×255mm×55mm
  • Weight 1.5KG(without HDD)
