QUBE SURF 720P 1MP 50M DOME CCTV CVI CAMERA

SKU 11209
P 899.00
In stock
1
Product Details

More CVI Dome Camera Options, Click here


Features:

  • 4 in 1 (CVI/TVI/AHD/Analog)
  • HD and SD output switchable
  • 3.6mm fixed lens
  • Max. IR length 50m, Smart IR
  • IP67, DC12V


Camera

  • Image Sensor 1/3" CMOS
  • Effective Pixels 1280(H)×720(V), 1MP
  • Electronic Shutter 1/30~1/100000s
  • Video Frame Rate 25/30fps@720P
Synchronization Internal
  • Min. Illumination 0.01Lux@F1.2(AGC ON), 0Lux IR on
  • Video Output 1-channel BNC high definition video output / CVBS video output (Can switch)
Camera Features
  • Max. IR LEDs Length Up to 50m (164feet)
  • Day/Night Auto / Manual
  • Noise Reduction 2D
  • WDR: DWDR
  • BLC Mode: BLC / HLC / DWDR
  • Gain Control: AGC
Lens
  • Focal length 3.6mm
  • Angle of View H: 72.3°(91.6°/46°)
  • Mount Type M12
  • Close Focus Distance 500mm (400mm/1300mm)
    19.69'' (15.75''/51.18'')
  • Pan/tilt Rotation Pan: 0° ~ 360° Tilt: 0° ~ 78° Rotation: 0° ~ 360°
General
  • Power Supply DC12V±25%
  • Power Consumption Max 2.9W (12V DC, IR on)
  • Working Environment --40°C ~ +60°C (-40°F ~ +140°F) / Less than 90% RH * Start up should be done at above -40°C (-40°F)
  • Ingress Protection &Vandal Resistance: IP67
  • Dimensions Φ106mm×93.7mm (Φ4.17"×3.69")
  • Weight 0.58kg
  • Casing: Aluminum
