QUBE RUFOUS D-MPDW1327-S / 3MP / ULTRA SMART FACE DETECTION / 2.7~12MM / POE

SKU 00362
P 8,190.00
In stock
1
Product Details

More IP Deluxe Dome Camera Options, Click here

Pls call our Stores to inquire about qualified credit card.



Specification

  • Model D-MPDW1327-S

Camera

  • Image Sensor : 1/3” 3Megapixel Aptina CMOS
  • Effective Pixels: 2048(H)x1536(V)
  • Scanning System: Progressive
  • Electronic Shutter Speed: Auto/Manual 1/3~1/10000
  • Min. Illumination: Color: 0. 1Lux/F1.2, B/W: 0.01Lux/F1.2; 0Lux/F1.2(IR on)
  • S/N Ratio: More than 50dB
  • Video Output: 1 port

Camera Features

  • Max. IR LEDs Length: 20m, Smart IR technology
  • Day/Night: Auto(ICR)/Color/B/W
  • Backlight Compensation: BLC / HLC / WDR (120dB)
  • White Balance: Auto
  • Gain Control: Auto/Manual
  • Noise Reduction: 3D
  • Privacy Masking: Up to 4 areas
  • EIS: Support
  • Ultra Defog: Support

Lens

  • Focal Length: 2.7 -12mm
  • Max Aperture F1.4
  • Focus Control: Manual
  • Angle of View: H: 82°~25°
  • Lens Type: Manual/ Auto Iris(DC)
  • Mount Type : Board-in Type

Video

  • Compression H.264 / MJPEG
  • Resolution: 3M(2048×1536)/1080P(1920×1080) / 720P(1280×720) /D1(704×576) /
  • CIF(352×288)
  • Frame Rate : Main Stream 3M/1080P/720P(1~25/30fps)
  • Sub Stream : D1/CIF(1 ~ 25/30fps)
  • Third Stream: 1080P/720P/D1(1 ~ 25/30fps)
  • Bit Rate: H.264: 32K ~ 8192Kbps ROI Up to 4 areas

Audio

  • Compression: G.711a / G.711u
  • Interface : 1/1 channel In/Out
  • Intelligent Function:
  • Smart detection: Tripwire

Intrusion

  • Scene change
  • Missing/Abandoned
  • Audio detect
  • Face detect

Network

  • Ethernet : RJ-45 (10/100Base-T)
  • Wi-Fi : N/A
  • Protocol: IPv4/IPv6, HTTP, HTTPS, SSL, TCP/IP, UDP, UPnP, ICMP, IGMP, SNMP, RTSP, RTP, SMTP, NTP, DHCP, DNS, PPPOE, DDNS, FTP, IP Filter, QoS, Bonjour
  • Compatibility : ONVIF, PSIA, CGI
  • Max. User Access: 20 users
  • Smart Phone: iPhone, iPad, Android, Windows Phone

Auxiliary Interface

  • Memory Slot: Micro SD, Max 64GB
  • RS485: N/A
  • Alarm: 1/1 channel In/Out
  • PIR Sensor Range: N/A

General

  • Power Supply: DC12V/AC24V, PoE(802.3af)
  • Power Consumption: Max 8W (IR on: +2W)
  • Working Environment: -20°C~+60°C , Less than 90%RH
  • Ingress Protection: IP66
  • Vandal Resistance: IK10
  • Dimensions: Φ5.9"×4.7"
  • Weight: 1.25kg
Gallary

1. Tripwire

Setup-event-IVS analyse-tripwire

(1) Enable Tripwire

(2) Draw rule, in the state of editing shows yellow, after the completion of the displayed shows blue, as pic 1 , and save it;

(3) when there is somebody intrude the area ,the display shows red.

2. Intrusion

Setup-event-IVS analyze-intrusion

(1) Enable Intrusion;

(2) Draw rule, in the state of editing shows yellow, after the completion of the displayed shows blue, as pic 2 , and save it;

(3) when there is somebody intrude the area ,the display shows red, as pic 3

3. Abandoned/missing

Setup-event-IVS analyse-intrusion

(1) Enable Abandoned/missing, when this function is enable, the Intrusion is untenable;

(2) Draw rule, in the state of editing shows yellow, after the completion of the displayed shows blue, as pic 4 , and save it;

(3) when something is missing or Abandoned,the display shows red.

Smart Detection:
