QUBE FISHEYE 4MEGAPIXEL PANORAMIC 180 DEGREE

SKU 00379
P 6,299.00
In stock
1
Product Details

More IP Deluxe Dome Camera Options, Click here

P1,112.82 / Month for 6 Months. Pls call our Stores to inquire about qualified credit card.



Daytime Demo:

Specification

  • Model Fisheye

Camera

  • Image Sensor 1/3” 4Megapixel progressive scan CMOS
  • Effective Pixels 2592(H)x1520(V)
  • Scanning System Progressive
  • Electronic Shutter Speed Auto/Manual 1/3(4)~1/10000
  • Min. Illumination 0.01lux/F2.0(color) ,0.001Lux@F2.0(B/W)
  • S/N Ratio More than 50dB
  • Video Output N/A

Camera Features

  • Max. IR LEDs Length N/A
  • Day/Night Auto(Electronic)/Color/B/W
  • Backlight Compensation BLC/HLC/DWDR
  • White Balance Auto/Manual
  • Gain Control Auto/Manual
  • Noise Reduction 3D
  • Privacy Masking Up to 4 areas

Lens

  • Focal Length 1.18mm
  • Max Aperture F2.0
  • Focus Control Manual
  • Angle of View H:180°
  • Lens Type Fixed lens
  • Mount Type Board-in Type

Video

  • Compression H.264/ MJPEG
  • Resolution:4M(2592×1520)/3M(2048×1520)/UXGA(1600×1200)/1.3M(1280×960)/720P(1280×720)/D1(704×576/704×480)/CIF(352×288/352×240)
  • Frame Rate Main Stream 4M(1~15fps)/ 3M (1 ~ 25/30fps)
  • Sub Stream D1/CIF(1 ~ 25/30fps)
  • Bit Rate H.264: 20K ~ 8192Kbps

Audio

  • Compression G.711a/G.711u/PCM
  • Interface 1/1 channel In/Out(Built in Mic)
  • Network
  • Ethernet RJ-45 (10/100Base-T)
  • Wi-Fi N/A
  • Protocol IPv4/IPv6, HTTP, HTTPS, SSL, TCP/IP, UDP, UPnP, ICMP, IGMP, SNMP, RTSP, RTP, SMTP, NTP, DHCP, DNS, PPPOE, DDNS, FTP, IP Filter, QoS, Bonjour
  • Compatibility ONVIF,PSIA,CGI
  • Max. User Access 20 users
  • Smart Phone iPhone, iPad, Android, Windows Phone

Auxiliary Interface

  • Memory Slot Micro SD, Max 64GB
  • RS485 N/A
  • Alarm 1/1 channel In/Out
  • PIR Sensor Range N/A

General

  • Power Supply DC12V,PoE
  • Power Consumption Max 6W
  • Working Environment -30°C~+60°C, Less than 95% RH
  • Ingress Protection N/A
  • Vandal Resistance IK10
  • Dimensions Φ110mm×54mm / 4.3" x 2" inches
  • Weight 0.25kg
