QUBE BELL D-MPD1327-IRV 1.3MP / 20M IR LENGHT / VARIFOCAL LENS / POE

SKU 00358
P 5,899.00
In stock
1
Product Details

More IP Deluxe Dome Camera Options, Click here


Pls call our Stores to inquire about qualified credit card.

Daytime Demo:

Nighttime Demo:



Specification

  • Model D-MPD1327-IRV

Camera

  • Image Sensor: 1/3” 1.3Megapixel Aptina CMOS
  • Effective Pixels: 1280(H)x960(V)
  • Scanning System : Progressive
  • Electronic Shutter Speed: Auto/Manual 1/4~1/10000
  • Min. Illumination: 0.05lux/F1.4(color), 0Lux/F1.4(IR on)
  • S/N Ratio : More than 50db
  • Video Output : 1 channel BNC(1.0Vp-p, 75Ω

Camera Features

  • Max. IR LEDs Length: 20m
  • Day/Night : Auto(ICR)/Color/B/W
  • Backlight Compensation : Off/BLC/HLC/DWDR
  • White Balance: Auto/Manual
  • Gain Control : Auto/Manual
  • Noise Reduction : 3D
  • Privacy Masking: Up to 4 areas

Lens

  • Focal Length: 2.7~9mm
  • Max Aperture: F1.2
  • Focus Control : Manual
  • Angle of View : H: 101°(Wide)~30.4°(Tele)
  • Lens Type : Manual/Auto Iris (DC)
  • Mount Type : Board-in Type

Video

  • Compression : H.264/ MJPEG
  • Resolution: 1.3M(1280×960) / D1(704×480)
  • Frame Rate: Main Stream 1.3M (1 ~ 25/30fps)
  • Sub Stream : D1(1 ~ 25/30fps)
  • Bit Rate: H.264: 16K ~ 8192Kbps

Audio

  • Compression : G.711a/G.711u(64kbps)/PCM(128kbps)
  • Interface: 1/1 channel In/Out

Network

  • Ethernet : RJ-45 (10/100Base-T)
  • Wi-Fi: N/A
  • Protocol : IPv4/IPv6, HTTP, HTTPS, SSL, TCP/IP, UDP, UPnP, ICMP, IGMP, SNMP, RTSP, RTP, SMTP, NTP, DHCP, DNS, PPPOE, DDNS, FTP, IP Filter, QoS, Bonjour
  • ONVIF : ONVIF Profile S
  • Max. User Access : 20 users
  • Smart Phone : iPhone, iPad, Android, Windows Phone

Auxiliary Interface

  • Memory Slot : Micro SD, Max 32GB
  • RS485 : N/A
  • Alarm : 1/1 channel In/Out
  • PIR Sensor Range: N/A

General

  • Power Supply: AC24V/DC12V, PoE(802.3af)
  • Power Consumption : Max 5W
  • Working Environment: -20°C~+60°C, Less than 90% RH
  • Ingress Protection: IK10
  • Vandal Resistance: IP66
  • Dimensions: Φ151mm×119mm
  • Weight: 1.25kg
